Features & Benefits
- Compact, heavy-duty design for years of reliable service
- Operates on shop air or inert gas
- Quick smoke generation
- Built-in safety pressure relief valve
- Pressure can be regulated from 0 to 28 PSI
- Large easy to read pressure decay gauge 0 to 30 PSI
- Non-toxic and non-corrosive smoke
- 10’ 12V power cables with durable clamps
- Heavy-duty 10’ smoke injection hose
- Velcro strap for hose and power cable storage
- Voltage: 12 VDC
- Input Pressure: Max 100 psi (7 bar)
- Output Pressure: Max 28 psi (190 kPa)
- Safety Pressure Relief: 120 (±5) psi
- Oil Fill Line Indicator: 3.4 oz (100 ml (±10 ml)
- Flow Meter: 0 – 0.040 in. (0 – 1.0 mm)
- Dimensions: 11.8 x 8.1 x 11 in (300 x 205 x 280 mm)
- Weight: 11.5 lbs (5.2 Kg) (Shipping Weight: 22 lbs (10 Kg))
- Power Consumption: Max 6.5 Amps
- Operating Temperature: 0°F to 140°F (-17°C to 60°C )
- Operating Humidity: No Restrictions
- Operating Altitude: No Restrictions
- Vapor Output Hose: 10 feet
- Power Cable: 10 feet
- Pressure Supply: Air/Inert gas
